Elation SIX+ BAR S LED Batten – Compact RGBLA+UV Pixel-Controlled Wash Light
Bring powerful color, precise control, and creative flexibility to your lighting design with the Elation SIX+ BAR S. An evolution of Elation’s popular SixBar 500, this compact LED batten combines an expanded color spectrum, enhanced output, and high-quality light in a versatile, IP65-rated fixture. Ideal for live productions, touring, houses of worship, architectural installations, and event lighting, the SIX+ BAR S delivers professional performance in a space-saving half-meter design.
Featuring six 20W RGBLA+UV LEDs, the SIX+ BAR S produces 4,435 lumens with a CRI of 90.9. Its advanced color engine creates vivid primaries, high-fidelity whites, and smooth color blending. Variable color temperature from 2400K to 8500K, CMY emulation, dim-to-warm fading, and a virtual gel library give lighting designers the tools to create everything from subtle ambient washes to bold, saturated effects.
Advanced RGBLA+UV Color Performance
- 6 x 20W RGBLA+UV LEDs: Deliver an extensive color palette with enhanced white-light quality and vivid saturated colors.
- 4,435-lumen output: Provides powerful illumination for accent lighting, wall washes, stage designs, and direct-view applications.
- CRI 90.9: Supports natural-looking color reproduction in professional lighting environments.
- Variable CCT from 2400K to 8500K: Adjust white light to match warm interiors, neutral tones, or cooler daylight looks.
- CMY emulation and virtual gel library: Simplify color selection and integrate familiar lighting-design workflows.
- Dim-to-warm fading: Create warmer color temperatures as the fixture dims.
Versatile Beam Control and Pixel Effects
- Large 50 mm lenses: Create a distinctive direct-view appearance for stages, installations, and creative pixel-strip designs.
- 20° beam angle without a lens: Delivers a more focused beam with a 33° field angle.
- Included frost filter: Broadens the beam to 30° with a 60° field angle for smoother, diffused coverage.
- Full pixel control: Unlock creative lighting effects and individualized LED control.
- 16-bit dimming: Multiple dimming modes and curves provide detailed intensity control and smooth fades.
- Electronic strobe: Add dynamic effects to performance and event lighting.
Professional Lighting Control and Connectivity
- DMX and RDM support: Integrate the SIX+ BAR S into professional lighting rigs with remote device management.
- Art-Net and sACN: Support network-based lighting control through IP65-rated RJ45 Ethernet connections.
- Aria x2 wireless device management: Simplify compatible wireless fixture setup and maintenance.
- 13 DMX channel modes: Select from multiple configurations to suit your programming requirements.
- SixBar 500 emulation: Five dedicated emulation modes help match the color and DMX behavior of existing SixBar 500 fixtures.
- Onboard controls: A four-button control panel and LED display provide direct access to fixture settings.
- IP65-rated connections: 5-pin XLR DMX, RJ45 Ethernet, and locking power connections support demanding production environments.
Flexible Mounting and Fixture Interconnection
- Integrated L-track on three sides: Provides versatile mounting and positioning options.
- End-to-end interconnection: Connect compatible fixtures using the dedicated fixture interconnection system.
- Flexible trunnion positioning: Multiple attachment points help optimize placement around objects and installation obstacles.
- Compact 501 mm housing: Fits applications where a shorter LED batten is easier to position and integrate.
- Included glare shield: Helps manage unwanted spill for wall-wash applications.
IP65-Rated Construction with Silent Cooling
Built for professional production and installation environments, the SIX+ BAR S features a fully IP65-rated housing for indoor and outdoor applications. Fanless convection cooling ensures silent operation, making it suitable for theaters, houses of worship, broadcast spaces, and other noise-sensitive environments. With an average LED life rating of 30,000 hours, it is designed for long-term use across a wide range of lighting applications.
Key Features
- Compact professional LED batten and pixel-controlled wash fixture
- 6 x 20W RGBLA+UV LED array
- 4,435 lumens measured by goniometer
- CRI 90.9 and TLCI 80
- Large 50 mm lenses for direct-view applications
- Full pixel control, electronic dimmer, and strobe
- Variable color temperature from 2400K to 8500K
- CMY emulation, dim-to-warm fading, and virtual gel library
- DMX, RDM, Art-Net, sACN, and Aria x2 wireless device management
- 13 standard DMX modes and five SixBar 500 emulation modes
- IP65-rated housing and connections
- Completely fanless convection cooling
- Integrated L-track mounting on three sides
- End-to-end fixture interconnection system
- 30,000-hour average LED life rating
Specifications
- LED Source: 6 x 20W RGBLA+UV LEDs
- Total Lumen Output: 4,435 lumens (goniometer)
- CRI: 90.9
- TLCI: 80
- Beam Angle, No Lens: 20°
- Field Angle, No Lens: 33°
- Beam Angle, Included Frost: 30°
- Field Angle, Included Frost: 60°
- Color System: RGBLA+UV
- Variable Color Temperature: 2400K–8500K
- Effects: Full pixel control, electronic dimmer, strobe
- Dimming: Variable 16-bit modes and curves
- Standard DMX Channel Modes: 13
- SixBar 500 Emulation Modes: 5
- Control Protocols: DMX, RDM, Art-Net, sACN
- Wireless Device Management: Aria x2
- Connections: IP65 5-pin XLR DMX In/Out, IP65 RJ45 Ethernet In/Out, IP65 locking power In/Out
- Display: LED display with four-button control panel
- Average LED Life: 30,000 hours
- Power Supply: AC 100–240V, 50/60Hz
- Maximum Power Consumption: 110W
- Power Thru Capacity: 10A; up to 10 units at 110V or 21 units at 240V
- Operating Temperature: 5°F to 113°F (-15°C to 45°C)
- Heat Output: 375.1 BTU/hr (±10%)
- Ingress Protection: IP65
- Dimensions: 19.7 x 6.9 x 8.1 in (501 x 176 x 206 mm)
- Weight: 14.88 lb (6.75 kg)
- Approvals: CE, cETLus, IP65, FCC, UKCA
- Firmware: V1.01 listed in supplied specifications
What's Included
- Elation SIX+ BAR S LED batten fixture
- Safety cable
- IP65 locking power cable
- Frost filter
- Glare shield
- Fixture interconnect splice
