Ovation F-145 WW

Description

The Modern 6-Inch Fresnel Replacement

The Chauvet Professional Ovation F-145WW is the perfect LED upgrade for venues looking to replace their aging 6-inch incandescent Fresnels. Delivering an output comparable to a 650W tungsten fixture, it offers a soft, beautifully flat field of warm white light (3096K) with an exceptional CRI of 97. This ensures that skin tones and costumes are rendered with the same natural warmth you expect from conventional lighting, but with a fraction of the power consumption and heat.

Motorized Zoom & Silent Control

Versatility is built into the design. The F-145WW features a smooth motorized zoom range of 16° to 65°, which can be adjusted remotely via DMX or manually at the fixture. This allows you to re-focus from a tight spot to a wide wash without ever climbing a ladder. With virtually silent operation and 16-bit dimming for ultra-smooth fades, it is perfectly suited for quiet theatres and broadcast studios.

Pro Features in a Compact Body

Despite its compact 6-inch form factor, this fixture is packed with professional features. It includes selectable PWM frequencies (up to 25,000 Hz) to ensure flicker-free performance on camera. The rear panel offers locking Seetronic Powerkon IP65 power connections with linking capability (up to 18 units at 120V), plus both 3-pin and 5-pin DMX ports for easy integration into any rig.

Key Features

Perfect Replacement: Comparable output to a 650W tungsten 6" Fresnel.
High CRI: 97 CRI ensures impeccable color rendering for natural skin tones.
Motorized Zoom: Wide 16° to 65° range controlled via DMX or onboard menu.
Silent Operation: "Virtually silent" performance ideal for theatre and film.
Smooth Dimming: 16-bit resolution for flawless fades to black.
Camera Ready: Selectable PWM settings for flicker-free video.
