MKD1096 2-Way Full Range Loudspeaker

MKD1096 2-Way Full Range Loudspeaker

EAW

$2,917.00
SKU:
MKD1096
Width:
28.00 (in)
Height:
15.00 (in)
Depth:
17.00 (in)
Shipping:
Ships free on orders over $35

MKD1096

2-Way Full Range Loudspeaker

The new MKD 1000 loudspeaker series is engineered to deliver the high output, broadband pattern control and exceptional fidelity that is required by real-world applications from stadiums to intimate music clubs.

Nominal beamwidth 90° x 60°

Features include:

  • High output passive or bi-amplified three-way performance
  • QX inspired 4in voice coil compression driver with extended bandwidth
  • Precision EAW signature broadband pattern control
  • Flexible mounting, weather protection, color and transformer options

Specifications

Frequency Response: 57Hz – 20kHz

Max SPL: 142dB

Operating Mode: Passive, Bi-Amp

Subsystem:

  • 2 x 10in Cone, 2.5in Voice Coil, Vented
  • 1 x 1.4in Exit, 4in Neodynium Compression Driver, Horn Loaded

Nominal Beamwidth:

  • Horizontal 90°
  • Vertical 60°

Power Handling:

  • LF/HF (External Crossover) 1000W @ 8ohms
  • LF/HF (Internal Crossover) 700W @ 8ohms
  • LF 700W @ 8ohms
  • HF 100W @ 8ohms

Connections: Barrier Strip

Dimensions:

  • Height: 27.2 in (690 mm)
  • Width: 14.8 in (377 mm)
  • Depth: 16.8 in (426 mm)
  • Weight: 70 lbs (27 kg)
