Mirage Par H IP

Mirage Par H IP

ADJ

MSRP: $859.95
$679.99
(You save $179.96 )
SKU:
MIR678
UPC:
810087373771
Width:
10.60 (in)
Height:
10.40 (in)
Depth:
11.10 (in)
Shipping:
Ships free on orders over $35

Mirage Par H IP

SKU: MIR678

Mirage Par H IP is an IP65-Rated, battery-powered, wireless DMX versatile LED Par designed for modern professionals looking for dynamic lighting solutions for event productions, installations and staging applications.

Specifications

Features:

  • 5 Pixel, Hex Color LED (RGBAL+UV) LED Par Battery or Wall Powered
  • Battery operation can be selected by the user for durations ranging from 5 to 20 hours
  • Built-In Programs
  • Variable White Color Temperature Control (2,700K ~ 9,900K)
  • User Selectable LED Refresh Rates (900Hz ~ 25K)
  • 6 User-Selectable Dim Modes
  • 4 User-Selectable Dim Curves
  • Electronic Strobe (0.3Hz ~ 11Hz)
  • Electronic Dimming

Source:

  • (5) 20W Hex Color RGBAL+UV LED's
  • 50,000 Hour Average Life
  • **may vary depending on several factors, including but not limited to environmental conditions, power/voltage, usage patterns (on-off cycling), control, and dimming.

Optical:

  • 2,300K ~ 9,900K White Color Temperature Range
  • Beam Angle: 17°

Physical:

  • IP65 Housing
  • Digital display
  • Adjustable, hanging / kickstand bracket

Control:

  • DMX512
  • Aria X2 Wireless Management / DMX System
  • Bluetooth
  • RDM and RDM Net Compatible
  • IR (Includes UCIR24 wireless remote)
  • (6) DMX Channel Modes (5, 6, 9A, 9B, 15 & 17 Channel modes)
  • On-board Manual Control Mode
  • Primary / Secondary Mode

Connections:

  • Chogori IP65 data locking connectors
  • Chogori IP65 power connectors

Dimensions & Weight:

  • Length: 11.1” (282mm) x 10.6” (269mm) x 10.4” (265mm)
  • Weight: 11.9 lbs. (5.4 kg)

Power:

  • AC100-240V/50Hz-60Hz Input
  • 60W Power Consumption
  • Link 14 pieces @120VAC or 28 pieces @ 230VAC

Battery:

  • Rechargeable Lithium-ion
  • Battery Capacity: 6,600mAh
  • Battery Voltage: 22.2V
  • Charge Time: 5 Hours (To Full)
  • Battery operation can be selected by the user for durations ranging from 5 to 20 hours. 5 Hour duration will operate at Full Output when battery is fully charged
  • Battery Cycles: 500

Thermal:

  • Ambient Operational Temperature: -4°F to 113°F (-20°C to 45°C)
  • Storage Temperature: -22°F to 113°F (-30°C to 45°C)

Certifications & IP Rating:

  • CE
  • cETLus (Pending)
  • FCC
  • IP65

Included Accessories:

  • (1) WIF901-POWER CABLE (WIF901-POWER CABLE), IP65 Chogori to Edison Locking Power Cable
  • (1) CHS5INDMX (CHS366) - 20” Chogori locking output data connector to Seetronic 5-pin, IP65, male input XLR connector adapter cable. (Must be used with STRxxx, 5pin DMX cables to create IP65 seal)
  • (1) CHS5OUTDMX (CHS373) - 20” Chogori locking input data connector to Seetronic 5-pin, IP65, female output XLR connector adapter cable. (Must be used with STRxxx, 5pin DMX cables to create IP65 seal)
  • (1) Floor / Mounting Bracket
  • (1) UCIR24 Remote

Optional Accessories:

  • CHS5INDMX (CHS366) - Replacement 20” Chogori locking output data connector to Seetronic 5-pin, IP65, male input XLR connector adapter cable. to Seetronic 5pin IP65 XLR DMX (Must be used with STRxxx, 5pin DMX cables to create IP65 seal)
  • CHS5OUTDMX (CHS373) - Replacement 20” Chogori locking input data connector to Seetronic 5-pin, IP65, female output XLR connector adapter cable
  • CHSIP65PIN (CHS386) - 10” Chogori locking input connector to Seetronic locking IP65 output power connector cable
  • CHSIP65POUT (CHS399) - 10” Chogori locking output connector to Seetronic locking IP65 input power connector cable
  • WIF901-POWER CABLE (WIF901-POWER CABLE) - Replacement Chogori Connector to IP65 Locking Power Cable

Specifications and documentation are subject to change without notice.
