L 2015

The L 2015 quick-charging unit automatically recharges two Sennheiser BA 2015 batteries.

The batteries are either inserted directly into the charger or remain in their bodypack transmitters/receivers of the evolution wireless G3 100, 300 and 500 Series, 2000 Series, Tourguide SK 2020-D and EK 1039. Several charging units can be daisy-chained and powered by one power supply unit.

Features

• Convenient quick-charging
• Two charging slots for batteries or bodypack transmitters/receivers
• Long battery life due to overcharge protection and regeneration of exhausted batteries

Specifications

Dimensions: 145 x 80 x 110 mm

Weight: 310 g

Charging time: ca. 2,5 h

Operating temperature: 0 à 40 °C

Power supply: 2 x 700 mA

Current consumption: 400 - 750 mA

Input voltage range: 10 - 20 V DC

Output voltage: 2 x 2,9 V

Cells: NiMH, 2 x 1,2V (BA 2015)

What's in the Box

• L 2015 charger
• Manual
