EZLink Strip Q6BT ILS
Fitted with ILS (Integrated Lighting System) and Bluetooth® wireless technology, this battery-powered quad-color (RGBA) LED linear wash light is a wireless wonder! But the wireless options don’t stop there. EZLink Strip Q6BT ILS also has D-Fi USB compatibility for wireless lead/follower or DMX control. Of course, Bluetooth® wireless technology means you can control directly from a smart phone or tablet without any additional hardware and being a part of the ILS ecosystem makes creating coordinated light shows across an unlimited number of different fixture types easy and fast. EZLink Strip Q6BT ILS has 3 zones of control to create amazing, automated effects, and you can generate a broad spectrum of colors and achieve natural-looking color temperatures with punchy amber LEDs.
Specifications
DMX Channels: 4, 6 or 16
DMX Connectors: 3-pin XLR
Max Unobstructed Distance: 150 ft (45.7 m)
Light Source: 4 LEDs (quad-color RGBA) 3 W, (1A), 50,000 hours life expectancy
Strobe Rate: 0 to 20Hz
Beam Angle: 47°
Field Angle: 79°
Maximum Run Time:
- All on: up to 8 hours
- Single color: up to 20 hours
Recharge Time: 4 hours
Operating Frequency: 2.4 GHz
Illuminance: 325 lux @ 2 m
Power Linking: 33 units @ 120 V; 54 units @ 230 V
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current:
- 17 W, 0.3 A @ 120 V, 60 Hz
- 17 W, 0.1 A @ 230 V, 50 Hz
Weight: 6.8 lb (3.1 kg)
Size: 19.7 x 4.2 x 5.4 in (500 x 108 x 139 mm)
Approvals: CE, RoHS ,UKCA, FCC
Cable Length: 5 ft (1.5 m)
Bracket Mounting Hole: 13 mm
Optional Controllers: IRC6, BTAir
Bluetooth Version: 4.2
WHAT'S INCLUDED
- EZLink Strip Q6BT ILS
- Power cord
- Quick Reference Guide
