Eternal Lighting EL Mount™ 4 pk.
Description: This is the EL Mount™ used to mount items such as the EchoMATE, CUBEecho MK2, Small compact Moving heads such as StellarSpotFX, LED Gobo Projector Ultra120 DMX or any other light.
The EL Mount™ was designed for use with tripod or weighted base and pole for mounting a light fixture or other lighting related device such as EchoMATE™ for elevated wireless DMX transmission of the signal strength.
Features & Technical Specifications:
- Easily Mount Lighting fixtures to the top of tripod or weighted pipe and base
- Weight: 0.75 lb (3/4 lb)
- Fits Tripod Diameter 1.250" - 1.620"
- Always use safe mounting pratice with weight mount to base width and weight ratio
- Maximum mounted light/fixture weight 22 lbs
- Steel construction powder coated black coating
- Knob Threads M8x1.25
- Dimension:
- Overall Lenth 4.75"
- Overall Width 3"
- Pipe Outer Diameter: 1.875"
- Pipe Inner Diameter: 1.625"
What is included:
- (4) EL Mount pipe device with threaded top and threaded side for set screw knob
- (4) Threaded Knob for top
- (4) Threaded knob for side set screw
- (8) Rubber Washers for set screw and top knob
